Air conditioning, ventilation, and heating systems are controlled by terminal devices. These devices regulate the airflow of the main duct system into individual rooms or regions. Just think of them as the traffic controllers of conditioned air, which controls the volume of air that is heated or cooled entering each room. Air distribution terminal units for hvac are positioned between the inhabited areas and the central HVAC system.
Before being distributed via wall registers or ceiling diffusers, they alter the temperature, volume, or both of the air after receiving it from the main supply duct. Because of this placement, the environmental conditions in various parts of a structure may be precisely controlled.
Different Terminal Unit Types
Terminal units with a single duct are the most commonly used type. One airstream is managed by these devices from the central system. VAV (variable air volume) boxes are included in this group. Depending on whether there is a need for heating or cooling, they adjust airflow. The VAV box decreases airflow when a room needs less conditioning. As demand rises, it expands to provide additional air.
When using dual duct terminals, two distinct supply ducts are used. Both carry air, one hot and the other cold. In order to reach the required temperature, the terminal unit blends these streams in different amounts. Although this system has superior control, it requires more intricate ducting and is more expensive to install.
Terminal units that are fan-powered have tiny fans that increase airflow as necessary. These are available in two styles. Units powered by series fans constantly run the fan, combining primary air from the central system with return air. Units powered by parallel fans only turn on the fan when heating mode is engaged or additional airflow is needed.
Regardless of the need for heating or cooling, constant air volume terminals keep the airflow constant. By warming the supply air instead of changing the volume, they regulate the temperature. They are easier to use, but they usually use more energy than their variable volume counterparts.
Zone Control Provides Energy Savings
By enabling zone-based HVAC control, terminal units significantly cut down on energy waste. Conventional systems heat or cool every space equally, treating entire buildings as separate zones. Energy is wasted in rooms that are empty or have differing needs while using this method.
With terminal units, every zone functions on its own. It is only during meetings that conference rooms are air-conditioned. Private offices cater to personal tastes. While nearby storage spaces have few air conditioners, server rooms provide constant cooling. Compared to systems with constant volume, this customized method reduces energy use by 20 to 40 percent.
Systems with variable air volume and terminal units drastically lower fan energy usage. The power consumption of fans is proportional to their speed cube. Energy utilization is reduced by about 50% when the fan speed is reduced by 20%. Terminal units provide significant savings by enabling the central air handler to slow down when fewer zones require conditioning.
Better Comfort and Temperature Management
Stable temperatures throughout a place are essential for occupant comfort. Terminal units are excellent at this. When zone thermostats send them signals, they react rapidly to temperature changes, modifying airflow in a matter of seconds.
Many times, conventional systems produce hot and cold areas. In contrast to peripheral zones, which lose heat through windows, interior zones produce heat from equipment and people. In order to make up for these variations, terminal units provide more heating to colder zones and more cooling to warmer ones.
Tighter temperature control is the end outcome. Fewer complaints about being too hot or too chilly are made by occupants. According to studies, offices with better temperature regulation see a 1–3% improvement in productivity. That productivity boost is the equivalent of adding two to six more staff to a company with 200 workers.
Additionally, terminal units avoid temperature fluctuations that are typical of on/off systems. Terminal devices adjust airflow constantly rather than simply blasting cold air until the thermostat is satisfied and then shutting off entirely.
Better Ventilation and Clean Air
Indoor air quality has an effect on both cognitive performance and health. Terminal equipment helps in the maintenance of proper levels of ventilation at different levels of airflow despite changes in the volume of airflow. The minimum airflow settings on advanced units guarantee that each zone receives enough fresh air regardless of the demand for heating or cooling.
In certain terminal units, outside air dampers are integrated right into the box. By doing this, zone-level ventilation may be precisely controlled instead of depending just on the central system mixing. Specific air quality requirements or spaces with greater occupancy rates are adequately ventilated without overventilating adjacent spaces.
Reduced drafts are another benefit of having control over airflow. To meet peak cooling loads, constant volume systems frequently release too much cold air into areas, resulting in uncomfortable air currents. The smoother air movement that occupants hardly notice is provided by variable volume terminal units, which decrease airflow under partial load conditions.
Lower Running Expenses
Lower utility bills are a direct result of lower energy consumption. The variable volume operation and zone management made possible by air distribution terminals save heating and cooling expenses. Buildings in moderate climates save the most since they spend the majority of the year operating at partial load.
Moreover, maintenance expenses drop. When airflow is throttled by terminal units, central air handlers operate at reduced pressures and speeds. The life of the equipment is increased, and the wear on belts, bearings, and motors is decreased by this kind of operation. Due to reduced airflow rates under partial load situations, filters have a longer lifespan.
The terminal units themselves need very little upkeep. The only moving parts in the majority are the small fans in fan-powered variants or the dampers in VAV units. The usual maintenance burden is represented by yearly inspections and sporadic replacements of damper actuators. Low lifecycle costs are maintained by this simplicity.
Conclusion
Over the course of decades of operation, terminal units provide consistent benefits. Energy savings add up over time, often resulting in overpaying for the initial outlay. As a building ages, increased comfort promotes tenant satisfaction and productivity.
Terminal units are guaranteed to remain operating as intended through routine commissioning. The correct operation of the control sequence, temperature control, and airflow rates is confirmed by routine testing. Resolving minor issues keeps them from becoming bigger ones that affect comfort or efficiency.
Future changes are protected against by the flexibility incorporated into terminal unit systems. Zones can be rearranged without requiring significant changes to the ductwork when buildings are remodeled or used for other purposes. HVAC infrastructure’s useful life is increased by this adaptability, which also postpones expensive system replacements.
